Instructions, D'installation, Figure 4 – Draw-Tite 50054 CUSTOM QUICK INSTALL BRACKETS User Manual
Page 21: Numéro de pièce
Instructions
d'installation
Numéro de pièce :
50054
©
2014 Cequent Performance Products
Feuille 6 de 6
50054N
2/24/2014
Rev. A
NÉCESSAIRE DE MONTAGE
RAPIDE SUR MESURE
Ram 2500
Mettre la traverse en place
TRAVERSES DE MONTAGE 30095 OU 30124 SEULEMENT
25-9/16”
23-5/8”
Utiliser des socles de sellette/curseur/col de cygne pour
placer la traverse de montage avant.
30124
POUR TRAVERSES DE MONTAGE
30124 OU 30095 SEULEMENT
Boulon
Imprimé au Mexique
Figure 4
30124
TRAVERSE POUR SELLETTE NON INCLUSE
CADRE / CHÂSSIS
CADRE / CHÂSSIS
REPÉRER LA TRAVERSE DEPUIS LE
REBORD DE LA PLATEFORME
H
AY
O
N
C
AM
IO
N
N
ET
T
E
C
AI
SSE
AVANT DU VÉHICULE
TROU DE MONTAGE DU
SUPPORT DE CADRE
LIGNE DE CENTRE DE L’ESSIEU
LIGNE DE CENTRE DE L’ATTELAGE
OUI
NON
DÉTAIL « A »
