8. Install the 10-amp fuse into the fuse holder

.

W

ARNING

All connections m

ust be complete for the

T-Connector to function properly. Test and
verify installation with a test light or trailer
once installed.

9. Secure all loose wir

ing and store the

trailer wiring harness inside the vehicle
when not in use

k

.

NO

TE

On some models the

T-connector maybe

routed and stored in either the spare tire
well or in the storage compartment next
to the vehicle’s access panel.

10. Reinstall the plastic tr

im panels, threshold,

storage covers, floor covering and other
items removed during installation, being
careful not to pinch or cut the wires.

W

ARNING

Ov

erloading circuit can cause fires.

DO NOT exceed lower of towing
manufacturer rating or:
• Max. stop/turn light: 1 per side (2.1 amps)
• Max. tail lights: (5 amps)
Read vehicle's owners manual &
instruction sheet for additional information.

ENGLISH

TOOLS NEEDED

T

rim Panel Remover,

Philips Head Screwdriver

1. Open the v

ehicle's rear tailgate, remove

cargo nets and cargo floor hatch to access
the spare tire area

d

.

2. T

emporarily remove all floor coverings,

exposing the spare tire compartment

ef

.

3. Using a tr

im panel tool, carefully pry

the threshold plate away from the vehicle,
being careful not to damage any clips

g

.

4. T

emporarily remove the vehicle's access

panel on the the passenger side to gain
access to the the vehicle's trailer wiring
harness

hi

.

5. Being careful not to damage clips

, partially

remove the lower interior trim panels on
passenger’s side of the vehicle only

j

.

6. Remo

ve the tape on the vehicle’s plug

and insert the T-Connector into the
vehicle’s trailer plug harness. Be sure
that the T-Connector is fully inserted
with locking tabs in place.

7. Locate a suitab

le mounting location

inside rear quarter panel on passenger
side, and clean area with 50/50 water/
alcohol solution where the converter will
be mounted.

118249-037

Rev. A

07/07/06

d

e

g

j

k

f

i

h

READ

THIS FIRST:

Read and f

ollow all vehicle warnings and

installation instructions before beginning
installation. Wear safety glasses and use
all safety precautions during installation.

LISEZ CECI EN PREMIER:
Lire et obser

ver toutes les consignes de sécurité

et les instructions avant de commencer l’installa-
tion. Durant l’installation, veiller à toujours porter
des lunettes de protection et respecter les
mesures de sécurité.

LEA

ESTO PRIMERO:

Lea y siga todas las adv

ertencias e instrucciones

de instalación del vehículo antes de empezar la
instalación. Use gafas de seguridad y todas las
precauciones de seguridad durante la instalación.

Installation Instr

uctions

Directives de Montage

Instrucciones de Instalación

T-Connector

Connecteur en T

Conector en T
