BEI Sensors Programmable Hall Device User Manual
Page 6
7230 Hollister Avenue, Goleta, California 93117 | Tel: 805-968-0782 | Fax: 805-968-3154 |
www.beisensors.com
6
Specification No.: 02135 Rev: 5-23-2013
PHD User Manual
Step 3: Connect BEI Programmable Sensor to PHD Programmer
1. Connect the 25-pin connector end of the Sensor Interconnect Cable to the Programmer.
2. Connect the 6-pin or 3-pin connector end of the Sensor Interconnect Cable to the BEI
Programmable Sensor.
3. Plug the AC Power Cord into an outlet and move the power switch on the Programmer to the
“1”or on position. The green and red lights should be lit.
• Verify that the Windows Driver Install was successful.
A small bubble should appear alearting you that the PHD has been detected.
• Click on the bubble to bring up the following screen.
• After a moment of searching, Windows will locate the drivers and the PHD Programmer
will be ready to use.
