16
4.5.5 Output computer formats
The QuickVu outputs support GTF (version 1.1), CVT (version 1.1) and DMT (version 1.0 rev 12) standards.
Other non-standard formats are supported via the custom format capability of the framework.
The QuickVu offers a list of pre-defined output formats.
The QuickVu offers 8 seamless inputs. Some inputs contain several plugs.
A plug corresponds to a socket or a connector on the rear panel.
The following types of plugs are available on the rear panel:
- HDMI
- Single DVI-D (HDMI compatible),
- 3G/HD/SD-SDI (BNC),
- Universal Analog (HD-15)
4.5.5 Output Computer formats
Format Size Aspect ratio
Frequency
50 Hz 60 Hz
VGA 640x480 4/3 Yes Yes
WVGA 848x480 16/9 Yes Yes
SVGA 800x600 4/3 Yes Yes
720p 1280x720 16/9 Yes Yes
XGA 1024x768 4/3 Yes Yes
WXGA 1280x768 5/3 Yes Yes
SWXGA 1360x768 16/9 Yes Yes
1366x768 1366x768 16/9 Yes Yes
WXGA2 1280x800 16/9 Yes Yes
SWXGAP 1366x800 5/3 Yes Yes
1152x864 4/3 Yes Yes
900p 1440x900 16/10 Yes Yes
1440x900 3/2 Yes Yes
1600x900 16/9 Yes Yes
1280x960 4/3 Yes Yes
SXGA 1280x1024 5/4 Yes Yes
1360x1024 4/3 Yes Yes
SXGAP 1400x1050 5/3 Yes Yes
4.6 Input specifications
Format Size Aspect ratio
Frequency
50 Hz 60 Hz
WSXGAP 1680x1050 16/9 Yes Yes
1080p 1920x1080 16/9 Yes Yes
2K 2048x1080 17/9 Yes Yes
UXGA 1600x1200 4/3 Yes Yes
WUXGA 1920x1200 16/9 Yes Yes
2048x1152 16/9 Yes Yes
