Analog Way QuickVu - Manual (Page 13)

13
4.2 Unpacking and inspection
• 1 x QuickVu (QVU150)
• 1 x Power supply cord
• 1 x Ethernet cross cable (for device update)
• 1 x Remote Control Software (RCS²)*
• 1 x Set of 6 audio 5-pin screw terminals
• 1 x Front rack ears (the parts are stowed in the packaging foam)
• 1 x User manual (PDF)*
• 1 x Quick start guide*
* User manual, quick start guide and the RCS² are available on www.analogway.com
Before racking and plugging any inputs and outputs, it is advised to power on the unit. Should you encounter
any issue, you must contact immediately your local distributor or dealer, or closest Analog Way technical
support offices (see chapter: 12. Contact information) .
Tabletop mounting: The QuickVu can be used directly on a table; the unit is equipped with 4 handy anti-slip
rubber feet.
Rack mounting: The QuickVu is compatible with a 19” enclosure. Please follow the instructions below to
install the device in a 19” rack.
Please put the ears on the unit thanks to the 4 provided screws.
Place the device in your rack. Attach the device to the rack by screwing 2 front ears on it (screws not included).
Rear fixing is also recommended, in particular for permanent installations.
Connect all of the cables of the device and attach them to the rack with the help of tie wraps.
IMPORTANT:
- The openings in the side of the device are for cooling. Do not cover these openings to avoid blocking air
circulation.
- Be sure that no weight in excess of 2 kg (4.4 Lbs.) is added onto the QuickVu.
- The maximum ambient operating temperature should not exceed 40°C (104°F).
- The rack and all mounted equipment in it must be reliably grounded according to national and/or local
electrical standards.
4.2 Unpacking and inspection
4.3 Rack mount information
Dismantling front handles of the device could invalidate warranty on after-sales services of your
QuickVu. It is strongly advised to avoid using front handles as rests for your QuickVu, they are
designed for manipulation purposes only.
If required, front handles of the device can be dismantled, but with caution. The original screws removed
must not be reintroduced to their location without handles in place. Substantial damages can occur,
including risk of electric shock from the main voltage. Only M4x12mm screws can be used. They are
supplied with the unit.
