Mako Technical Manual V2.0.4
31
Filter and lenses
Mako G-223
Mako G-419
Focal length for type 2/3*sensors Distance = 500 mm Distance = 1000 mm
4.8 mm 1162 mm x 617 mm 2335 mm x 1240 mm
6 mm 927 mm x 492 mm 1865 mm x 991 mm
6.5 mm 855 mm x 454 mm 1721 mm x 914 mm
8 mm 692 mm x 368 mm 1396 mm x 742 mm
10 mm 552 mm x 293 mm 1114 mm x 597 mm
12 mm 458 mm x 243 mm 927 mm x 492 mm
16 mm 341 mm x 181 mm 692 mm x 369 mm
25 mm 214 mm x 114 mm 439 mm x 223 mm
35 mm 150 mm x 79 mm 310 mm x 165 mm
50 mm 101 mm x 54 mm 214 mm x 114 mm
75 mm 64 mm x 34 mm 139 mm x 74 mm
90 mm 51 mm x 27 mm 114 mm x 60 mm
* A 2/3 inch lens may cause vignetting (1 inch lens recommended)
Table 9: Focal length vs. field of view (Mako G-223)
Focal length for type 1 sensors Distance = 500 mm Distance = 1000 mm
8 mm 692 mm x 692mm 1396 mm x 1396 mm
10 mm 552 mm x 552 mm 1114 mm x 1114 mm
12 mm 458 mm x 458 mm 928 mm x 928 mm
16 mm 340 mm x 340 mm 692 mm x 692 mm
25 mm 214 mm x 214 mm 439 mm x 439 mm
35 mm 150 mm x 150 mm 310 mm x 310 mm
50 mm 101 mm x 101 mm 214 mm x 214 mm
75 mm 64 mm x 64 mm 139 mm x 139 mm
90 mm 51 mm x 51 mm 104 mm x 104 mm
Table 10: Focal length vs. field of view (Mako G-419)
