Mako Technical Manual V2.0.4
18
Specifications
Mako G-125B/C
Feature Specification
Sensor Type 1/3 (diag. 6 mm) progressive scan SONY IT CCD ICX445ALA/AQA
with EXview HAD microlens
Effective chip size 4.8 mm x 3.6 mm
Cell size 3.75 μm x 3.75 μm
Resolution (maximum) 1292 x 964 pixels
Lens mount C-Mount: 17.526 mm (in air); Ø 25.4 mm (32 tpi)
Maximum protrusion: 9.8 mm (see
figure 18 )
CS-Mount: 12.526 mm (in air); Ø 25.4 mm (32 tpi)
Maximum protrusion: 4.8 mm (see
figure 20 )
ADC 14 bits
Pixel format Only monochrome: Mono8, Mono12Packed, Mono12
Only color: BayerRG8, BayerRG12, BayerRG12Packed, Mono8,
RGB8Packed, YUV411Packed, YUV422Packet, YUV444Packed,
BGR8Packed
Frame rates Up to 30 fps
Gain control Manual: 0–30 dB (1 dB/step); auto gain (select. ROI)
Exposure time 12 μs to 84 s; auto shutter (select. ROI)
External trigger event Rising edge, falling edge, any edge, level high, level low
External trigger delay 0 to 42 s in 1 μs increments
Fixed rate control 0.012 fps to maximum frame rate (steps of 0.001 fps)
Imaging modes Free-running, external trigger, fixed rate, software trigger
Sync Out modes Trigger ready, trigger input, exposing, readout, imaging, strobe, GPO
Internal image memory 64 MByte, up to 52 frames
Smart functions Auto gain control, auto exposure control, 64 MByte image memory,
binning (monochrome binning, also for color cameras; but no color
binning), LUT, gamma, config files (user sets)
Only color: auto white balance, hue, saturation
I/O One configurable optocoupled input
Three configurable optocoupled outputs
Table 4: Specification Mako G-125B/C
Note

Maximum protrusion means the distance from lens flange to
the glass filter in the camera.
Note

The number of frames (StreamHoldCapacity) depends on
resolution, pixel format, and GVSP packet size. Stated number of
frames is typical for full resolution, Mono8/Bayer8, and
GevSCPSPacketSize = 8192.
