Mako Technical Manual V2.0.4
22
Specifications
Mako G-419B/C (NIR)
Feature
Specification
Sensor
Type 1/1 (diag. 15.93 mm) CMOS sensor: CMOSIS CMV4000 (mono-
chrome/color) with microlenses and global shutter
The monochrome version is also available as NIR enhanced variant
(Mako G-419B NIR). Except for the sensor response, the technical
data of the NIR enhanced variant are identical with Mako G-419B.
Effective chip size
11.26 mm x 11.26 mm
Cell size
5.5 μm x 5.5 μm
Resolution (maximum)
2048 x 2048 pixels
Lens mount
C-Mount: 17.526 mm (in air); Ø 25.4 mm (32 tpi)
Maximum protrusion: 10.8 mm (see
CS-Mount: 12.526 mm (in air); Ø 25.4 mm (32 tpi)
Maximum protrusion: 5.8 mm (see
ADC
12
bits
Pixel format
Only monochrome: Mono8, Mono12Packed, Mono12
Only color: BayerGB8, BayerGB12, BayerGB12Packed, Mono8,
RGB8Packed, BGR8Packed, RGBA8Packed, BGRA8Packed,
YUV411Packed, YUV422Packet, YUV444Packed
Frame rates
Up to 26.3 fps
Gain control
Manual: 0–26 dB (1 dB/step); auto gain (select. ROI)
Exposure time
41 μs to 153 s; auto shutter (select. ROI)
External trigger event
Rising edge, falling edge, any edge, level high, level low
External trigger delay
0 to 306 s in 1 μs increments
Fixed rate control
0.01 fps to 26.37 fps (steps of 0.1 fps)
Imaging modes
Free-running, external trigger, fixed rate, software trigger
Sync Out modes
Trigger ready, trigger input, exposing, readout, imaging, strobe, GPO
Internal image memory
64 MByte, up to 15 frames
Smart functions
Auto gain control, auto exposure control, 64 MByte image memory,
no binning, LUT, gamma, config files (user sets)
Only color: auto white balance, hue, saturation
Table 6: Specification Mako G-419B/C
Note
Maximum protrusion means the distance from lens flange to
the glass filter in the camera.
Note
The number of frames (StreamHoldCapacity) depends on
resolution, pixel format, and GVSP packet size. Stated number of
frames is typical for full resolution, Mono8/Bayer8, and
GevSCPSPacketSize = 8192.
