Mako Technical Manual V2.0.4
16
Specifications
Specifications
Mako G-032B/C
Caution
Before operating any AVT camera, read the safety instructions
and ESD warnings in the AVT GigE Installation Guide.
Caution
Due to the small packaging and high speed of Mako cameras,
take special care to ensure that the housing temperature of
the camera does not exceed 50 °C. Following are general
guidelines for heat dissipation:
•
Mount the camera on a heat sink such as a metal bracket.
•
Lenses, when attached to a camera, act as a heat-sink and
help reduce housing temperature.
•
Ensure sufficient air flow. Use a fan if necessary.
Feature
Specification
Sensor
Type 1/3 (diag. 6 mm) progressive scan SONY IT CCD ICX424AL/AQ with
HAD microlens
Effective chip size
4.9 mm x 3.6 mm
Cell size
7.4 μm x 7.4 μm
Resolution (maximum)
658 x 492
pixels
Lens mount
C-Mount: 17.526 mm (in air); Ø 25.4 mm (32 tpi)
Maximum protrusion: 9.8 mm (see
CS-Mount: 12.526 mm (in air); Ø 25.4 mm (32 tpi)
Maximum protrusion: 4.8 mm (see
ADC
14 bits
Pixel format
Only monochrome: Mono8, Mono12Packed, Mono12
Only color: BayerRG8, BayerRG12, BayerRG12Packed, Mono8,
RGB8Packed, YUV411Packed, YUV422Packet, YUV444Packed,
BGR8Packed
Frame rates
Up to 102 fps
Gain control
Manual: 0–30 dB (1 dB/step); auto gain (select. ROI)
Exposure time
10 μs to 93 s; auto shutter (select. ROI)
Table 3: Specification Mako G-032B/C
Note
Maximum protrusion means the distance from lens flange to
the glass filter in the camera.
