menu:

Configuration - IP Filter

Step 1

From the Filtering Configuration screen, select the WAN profile of
interest from the pull down menu. For example, if your only need is to
access the Internet, you should only select the Internet access profile.

Step 2

Select send or discarded as desired, which is equivalent to allow and
disallow, respectively.

Step 3

If you are just starting, click Add to add a new selection rule. If you have
previously defined rules, you will see those rules shown as entries in the
rule table, and you can edit the rule by first highlighting the desired entry
in the rule table followed by clicking the Edit button.

Step 4

In case of adding a new selection rule, the following screen shows:

Filtering Configuration

ISP

Incorrect configuration may cause undesireable behavior. Please refer to the user

manual for more details

All IP packets for this profile

will be

discarded except for those matching one or more of the following rules.

sent

(Warning: Clicking the round button above changes the setting and takes effect immediately!)

Delete

Add

Edit

Select to

Edit

Rule

Number

Rule

Name

Local IP

Address(es)

Local

Port(s)

Remote IP

Address(es)

Remote

Port(s)

FTPin

192.168.168.22

Any

HTTPout

Any

Manuf

192.168.168.110-
192.168.168.134

Any
