Cajun P550/P880 Manager User Guide
Configuring the Cajun Switch Using the P550/P880 Manager
2-39
Figure 2-11. Device Manger Window (with apply and cancel
buttons shown)
To set the port speed:
1. Start Cajun P550/P880 Manager. For information about
starting the Cajun P550/P880 Manager, refer to "Starting the
Cajun P550/P880 Manager" earlier in this chapter.
2. In the switch representation, select a port.
3. In the Cajun P550/P880 Device Manager tool bar, click 10 or
100.
4. Click apply to save the new port speed, or cancel to restore
previous settings (Figure 2-11).
Enabling a Port
The Enable port icon is represented as a port with a check mark.
Hold the cursor over the icon to display the icon name: Enable. To
enable a port:
1. Start Cajun P550/P880 Manager. For information about
starting the Cajun P550/P880 Manager, refer to "Starting the
Cajun P550/P880 Manager" earlier in this chapter.
2. In the switch representation, select the port to enable.
3. In the Cajun P550/P880 Device Manager tool bar, click
Enable Port.
4. Click apply to enable the port, or cancel to restore previous
settings (Figure 2-11).
