2-30
Chapter 2
Cajun P550/P880 Manager User Guide
5. From the Trunk Mode pull-down menu, select the option
(excluding Clear) to indicate that the port is a trunk and to
select the appropriate VLAN trunking format if the port is
connected to another switch. Table 2-5 describes the VLAN
Trunk Mode options:
6. From the Frame Tags pull-down menu, select whether you
want to Ignore or Use received Frame VLAN tags. If you
ignore VLAN tags on incoming frames, the frames are bound
to the port’s default VLAN.
7. From the VLAN Binding pull-down menu, select a VLAN
Binding Type for this port. Table 2-6 describes the VLAN
Binding Options.
Table 2-5. VLAN Trunking Mode Options
VLAN Mode Applies the following format to packets
entering this port:
Clear No VLAN tag. This is the default setting.
IEEE-802.1Q The IEEE 802.1Q Ethernet VLAN tagging scheme.
3Com The proprietary 3Com tagging scheme.
Multi-layer A Cisco VLAN tagging scheme.
