DISPlay
The DISPlay subsystem monitors the channel state of a selected module (or
card) in a switchbox. This subsystem operates only with mainframes which
have a display, such as the Agilent 75000 Series B mainframe (Agilent
Model Number E130lB).
Subsystem Syntax DISPlay
:MONitor
:CARD
<number> | AUTO
[:STATe] <mode>
MONitor:CARD DISPlay:MONitor CARD <number> | AUTO selects the module in a
switchbox to be monitored.
Parameters
Parameter Name Parameter Type Range of Values
<number> | AUTO numeric 1 - 99
Comments
•
Selecting a Specific Module to be Monitored: Use the DISPlay:
MONitor:CARD command to send the card number for the
switchbox to be monitored.
•
Selecting the Present Module to be Monitored: Use the DISPlay:
MONitor:CARD AUTO command to select the last module
addressed by a switching command (e.g., [ROUTe:]CLOSe).
•
*RST Condition: DISPlay:MONitor:CARD AUTO
Example Select Module #2 in a Switchbox for Monitoring:
DISP:MON:CARD 2 Selects module #2 in a switchbox
Chapter 5 Agilent E1364A Form C Switch Command Reference 47
