Installation and Connection
Internal analog
speed ref. setting External analog
speed ref. setting
3.5.5 Analog
Output
3.5.4 Analog
Inputs
1 10 11 14 15 GND 16 20 22 X2A
1 10 11 14 GND 15 16 22
+
X2A
3.5.3 Digital
Inputs
In case of inductive load on the relay output, protective wiring must be
provided (e.g. free-wheeling diode)!
1 7 8
R = 3...10 kW
GND 5 22
X2A 1 5 8 22 GND 7 X2A
+
0(4)...20 mADC
Ri = 250 W
0...±10 VDC
Ri = 30 kW
+
1 22 5 7 8 GND
+10 VDC / 5 mA
X2A
3.5.6 Relay
Outputs
Rin = 2.1 kΩ
Use of external voltage supply
Use of internal voltage supply
20...30 VDC Regulated
optional:
24 25 26 GND 27 28 29
max.30VDC/1A
+
-
X2A
