PMM 9010
PMM 9030
PMM 9060
Main features at a glance
• The state-of-the-art full compliance 30 MHz EMI Digital Receiver is
the platform of the system. Based on direct Analog to Digital
conversion and sophisticated computation, it offers calibration-free
operation on almost all of its key components, i.e. RBW filters,
detectors, demodulation… while the RF front-end is self-calibrated
by the internal, precise RF signal generator.
• All the units are uniquely compact and lightweight: the low
frequency unit (PMM 9010) is about 4,1 kg and the high frequency
extensions are about 2 kg. All are battery operated.
• Hardware and Firmware are designed around the current EMC
standards, and ready to upgrade to future changes in the same.
• Powerful digital Click Analyzer is fully compliant with the latest
CISPR specifications, 1 (internal option) or 4 (external option) channels.
Performance characteristics highlights
• Frequency ranges from 10 Hz to 30 MHz; 3 GHz; 6 GHz.
• Full compliance with the latest edition of CISPR 16-1-1 standard,
including RMS-AVG detector, APD function, click measurements, etc.
• Commercial and military standards met within the frequency range
• CISPR and MIL-STD RBW filters.
• Integrated preamplifier (all units) and pulse limiter (only PMM 9010).
• Mostly maintenance and calibration free; service done in minutes.
• Excellent RF characteristics.
• Built-in tracking signal generator up to 30 MHz (PMM 9010).
• Multimode functions: sweep, spectrum analyzer, scalar network
analyzer, manual receiver.
• Smart Detector: a “productivity booster” feature specifically designed
to dramatically improve test speed.
Traditional Receiver
Innovative Digital Receiver
