25

Power requirements

100-120 V 50/60 Hz, 220-240 V 50/60 Hz

(automatically

selected)

< 400 W typ 650 W maximum

Operating temperature range

0 to 55 °C

1

Storage temperature range

1

–40 to 70 °C

Altitude

0 to 4600 m (15,00 ft)

Humidity

80% relative humidity (maximum) for temperatures up

to 31 °C, decreasing linearly to 50% relative humidity at

40

°C.

Environmental Testing

Samples of this product have been type tested in

accordance with the Agilent Environmental Test Manual

and verified to be robust against the environmental

stresses of storage, transportation and end-use; those

stresses include but are not limited to temperature,

humidity, shock, vibration, altitude and power line

conditions. Test methods are aligned with IEC 60068-2

and levels are similar to MIL-PRF-28800F Class 3.

2

EMC

Meets the conducted and radiated interference and

immunity requirements of IEC/EN 61326-1. Meets radiated

emission requirements of CISPR Pub 11/1997 Group 1 class A.

Storage

Memory is shared by instrument states, user data files,

sweep list files, and waveform sequences. There is 14 MB

of flash memory available in the E8267D PSG. With

Option 009, there is an additional 8 GB of storage.

Depending on how the memory is utilized, a maximum

of 1000 instrument states can be saved.

Security Display

blanking

Memory clearing functions (See Application Note

"Security Features of Agilent Technologies Signal

Generators", Part Number E4400- 90621.) With

Option 009, all user-written files are stored on an 8 GByte

removable flash memory card.

Compatibility

Agilent 83550 Series Millimeter Heads and

OML millimeter source modules

Agilent 8757D scalar network analyzers

Gigatronics 8003 scalar network analyzer

Agilent EPM Series power meters

Self-test

Internal diagnostic routine tests most modules (including

microcircuits) in a preset condition. For each module,

if its node voltages are within acceptable limits, then

the module “passes” the test.

Weight

< 25 kg (54 lb.) net, < 33 kg (74 lb.) shipping

Dimensions

178 mm H x 426 mm W x 515 mm D

(7” H x 16.8” W x 20.3” D)

Recommended calibration cycle 24 months

General specifications

1. Storage below –20 °C instrument states may be lost.
2. As is the case with all signal generation equipment, phase noise specifications are not warranted in a vibrating environment.
