Sync out A and B:
The logical trigger signal 1
or logical trigger signal 2
or logical strobe signal 1
or logical strobe signal 2
can be routed by a fully
fl exible internal switch
matrix to Sync Out A or
Sync Out B.
Couple/uncouple channels
External In
Trigger mode
Waveform type
Advanced mode
Channel 2:
Differential output
Channel 1:
Differential
output
USB 2.0A
USB 2.0A
USB 2.0B
LAN
GPIB
10 MHz Ref Out
10 MHz Ref In
Modulation
In 1, 2
