Waveform Types • Standard waveforms: pulse, sine, square, ramp, noise, arbitrary
• Predefi ned arbitrary waveforms: exponential rise, exponential fall, sin(x)/x, cardiac and DC
• Pulse, sine, ramp, noise and arbitrary measured with 50 Ω source impedance into 50 Ω load impedance.
Pulse characteristics
81150A 81160A
Frequency range
High bandwidth amplifi er
High voltage amplifi er
1 μHz to 120 MHz
1 μHz to 50 MHz 1 μHz to 330 MHz
Frequency resolution 1 μHz 1 μHz
Pulse width
Range
High bandwidth amplifi er
High voltage amplifi er
Resolution
Accuracy
4.1 ns to (period - 4.1 ns) typ.
10 ns to (period - 10 ns)
100 ps, 6 digits
± 500 ps ± 50 ppm 1.5 ns to (period - 1.5 ns) spec.
100 ps, 6 digits
± 300 ps ± 50 ppm
Transition time
(independent rise and fall)
Range
High bandwidth amplifi er
High voltage amplifi er
Resolution
Accuracy
High bandwidth amplifi er
High voltage amplifi er
2.5 ns to 1000 s (10% to 90%)
7.5 ns to 1000 s (10% to 90%)
100 ps, 6 digits
± 500 ps ± 50 ppm
-1000 ps to +500 ps ± 50 ppm
1.0 ns to 1000 s (10% to 90%)
100 ps, 6 digits
± 300 ps ± 50 ppm
Overshoot 2% typ. (1) 4% typ. (2)
1) Overshoot disappears for transitions times > 5 ns (high bandwidth amplifi er) and > 15 ns (high voltage amplifi er).
2) Overshoot disappears for transition times > 2 ns.
Sine characteristics
81150A 81160A
Frequency range
High bandwidth amplifi er
High voltage amplifi er
1 μHz to 240 MHz
1 μHz to 50 MHz 1 µHz to 500 MHz
Frequency resolution 1 μHz 1 μHz
Harmonic distortion
(High bandwidth amplifi er
50 Ω into 50 Ω)
Harmonic distortion
(High voltage amplifi er
50 Ω into 50 Ω)
Non-harmonic (spurious) distortion
1 μHz to 20 MHz -60 dBc typ.
20 MHz to 200 MHz -55 dBc typ.
200 MHz to 240 MHz -50 dBc typ.
1 μHz to 1 MHz -50 dBc typ.
1 MHz to 10 MHz -55 dBc typ.
10 MHz to 280 MHz -50 dBc typ.
280 MHz to 330 MHz -45 dBc typ.
330 MHz to 500 MHz -43 dBc typ.
SSB phase noise (10 kHz offset)
1 MHz
10 MHz
100 MHz
240 MHz
500 MHz
-119 dBc/Hz typ.
-115 dBc/Hz typ.
-93 dBc/Hz typ.
-115 dBc/Hz typ.
-115 dBc/Hz typ.
-110 dBc/Hz typ.
-100 dBc/Hz typ.
1 V
PP
3 V
PP
1 μHz to 2 MHz < -62 dBc spec. < -62 dBc spec.
2 MHz to 10 MHz < -57 dBc spec. < -52 dBc spec.
10 MHz to 35 MHz < -45 dBc spec. < -40 dBc spec.
35 MHz to 70 MHz < -35 dBc spec. < -30 dBc spec.
70 MHz to 240 MHz < -22 dBc spec. < -17 dBc spec.
10 V
PP
1 μHz to 8 MHz < -40 dBc
8 MHz to 50 MHz < -25 dBc
1 V
PP
3 V
PP
1 µHz to 2 MHz < -65dBc spec. < -63 dBc spec.
2 MHz to 10 MHz < -62dBc spec. < -53 dBc spec.
10 MHz to 50 MHz < -50 dBc spec. < -40 dBc spec.
50 MHz to 200 MHz < -30 dBc spec. < -27 dBc spec.
200 MHz to 500 MHz < -22 dBc spec. < -20 dBc spec.
