29
Download Times Block transfer is the fastest way to download waveforms to both the Agilent 81150A and
81160A Pulse Function Arbitrary Noise Generators.
Download times: block transfer (meas.)
81150A 81160A
USB 2.0 GPIB LAN USB 2.0 GPIB LAN
1 k points 31 ms typ. 35 ms typ. 35 ms typ. 23 ms typ. 44 ms typ. 27 ms typ.
8 k points 65 ms typ. 120 ms typ. 80 ms typ. 68 ms typ. 198 ms typ. 86 ms typ.
64 k points 700 ms typ. 1 s typ. 730 ms typ. 330 ms typ. 1.36 s typ. 449 ms typ.
256 k points 1.25 s typ. 5.4 s typ. 1.75 s typ.
512 k points 2.9 s typ. 5.2 s typ. 3.7 s typ.
Download times: integer comma separated values (meas.)
81150A 81160A
USB 2.0 GPIB LAN USB 2.0 GPIB LAN
1 k points 220 ms typ. 200 ms typ. 220 ms typ. 214 ms typ. 188 ms typ. 181 ms typ.
8 k points 1.8 s typ. 1.6 s typ. 1.4 s typ. 1.6 s typ. 1.45 s typ. 1.39 s typ.
64 k points 14.2 s typ. 12.6 s typ. 12 s typ. 13.0 s typ. 11.5 s typ. 11.0 s typ.
Download times: fl oat comma separated values (meas.)
81150A 81160A
USB 2.0 GPIB LAN USB 2.0 GPIB LAN
1 k points 290 ms typ. 280 ms typ. 270 ms typ. 297 ms typ. 256 ms typ. 236 ms typ.
8 k points 2.4 s typ. 2.1 s typ. 1.9 s typ 2.23 s typ. 1.98 s typ. 1.8 s typ
64 k points 20 s typ. 16 s typ. 15 s typ. 18.2 s typ. 15.7 s typ. 14.3 s typ.
