30
General Specifi cations
81150A 81160A
Power supply 100 V to 240 V ~, 50 to 60 Hz
100 V to 127 V ~, 50 to 400 Hz 100 V to 240 V ~, 50 to 60 Hz
100 V to 127 V ~, 50 to 400 Hz
Power consumption 110 W nom. 90 W nom.
Operating temperature 0 to 50 ºC 0 to 55 ºC
Operating altitude Up to 2000 m Up to 2000 m
Storage temp. -40 to 70 °C -40 to 70 °C
Stored states 4 named user confi gurations and factory default 4 named user confi gurations and factory default
Power on state Default or last state Default or last state
Interface 2 x USB 2.0 standard A,
1 x USB 2.0 standard B,
GPIB and LAN 2 x USB 2.0 standard A,
1 x USB 2.0 standard B,
GPIB and LAN
Programming language SCPI-1997
IEEE-488.2
LXI compliant to LXI class C (rev. 1.1) SCPI-1997
IEEE-488.2
LXI compliant to LXI class C (rev. 1.1)
Dimensions (WxHxD)
Bench top
Rack mount
439 mm x 108 mm x 456 mm
428 mm x 89 mm x 439 mm 439 mm x 108 mm x 456 mm
428 mm x 89 mm x 439 mm
Weight 8 kg 8 kg
Safety designed to IEC61010-1
UL61010
CSA22.2 61010.1 certifi ed IEC61010-1
UL61010
CSA22.2 61010.1 certifi ed
EMC tested to IEC61326 IEC61326
Warm up time 30 min. 30 min.
Calibration interval 2 years recommended 2 years recommended
Warranty 1 year standard 1 year standard
Cooling requirements When operating the instrument choose a location that
provides at least 80 mm of clearance at rear, and at
least 30mm of clearance at each side When operating the instrument choose a location that
provides at least 80 mm of clearance at rear, and at
least 30mm of clearance at each side
Defi nitions
Specifi cation (spec.)
The warranted performance of a calibrated instrument that has been stored for a minimum of 2 hours within the operating temperature
range of 0 °C to 55 °C and after a 45-minute warm up period. Within ± 10 °C after autocal. All specifi cations include measurement
uncertainty and were created in compliance with ISO-17025 and Z540 methods. Data published in this document are specifi cations (spec)
only where specifi cally indicated.
Typical (typ.)
The characteristic performance, which 80% or more of manufactured instruments will meet. This data is not warranted, does not include
measurement uncertainty, and is valid only at room temperature (approximately 23 °C).
Nominal (nom.)
The mean or average characteristic performance, or the value of an attribute that is determined by design such as a connector type,
physical dimension, or operating speed. This data is not warranted and is measured at room temperature (approximately 23 °C).
Measured (meas.)
An attribute measured during development for purposes of communicating the expected performance. This data is not warranted and is
measured at room temperature (approximately 23 °C).
Accuracy
Represents the traceable accuracy of a specifi ed parameter. Includes measurement error and timebase error, and calibration source
uncertainty.
