Advanced Modes

Three advanced modes exist:

• Modulation: selects the modulation type: AM, FM, PM, FSK, PWM

• Sweep: for frequency sweeps

• Bursts: repeats selected waveform n times

A modulation input (for AM, FM, PM, FSK, PWM) for each channel is provided on the
back-panel. In the two channel instrument one channel can also modulate the other
channel.

Modulation In 1/modulation In 2

81150A

81160A

Input range (full scale)

Selectable ±2.5 V or ±5 V

±2.5 V

Frequency range

DC to 10 MHz

Input impedance

Selectable 10 kΩ, 50 Ω nom.

Connector

BNC, back panel

81150A

81160A

Carrier waveforms

Sine, square, ramp, arbitrary

Internal modulation

Sine, square, ramp (up, 50%, down), noise,
arbitrary

Modulation frequency
Internal
External

1 mHz to 10 MHz
DC to 10 MHz

1 mHz to 50 MHz
DC to 10 MHz

Depth

0% to 120%

Double-sideband suppressed carrier

Selectable on/off

Source

Internal, external, channel

81150A

81160A

Carrier waveforms

Sine, square, ramp, arbitrary

Internal modulation

Sine, square, ramp (up, 50%, down), noise,
arbitrary

Modulation frequency
Internal
External

1 mHz to 10 MHz
DC to 10 MHz

1 mHz to 50 MHz
DC to 10 MHz

Deviation range

1 μHz to 240 MHz

(1)

1 µHz to 500 MHz

(1)

Source

Internal, external, channel

81150A

81160A

Carrier waveforms

Sine, square, ramp, arbitrary

Internal modulation

Sine, square, ramp (up, 50%, down), noise,
arbitrary

Modulation frequency
Internal
External

1 mHz to 10 MHz
DC to 10 MHz

1 mHz to 50 MHz
DC to 10 MHz

Deviation range

0 to 360

Source

Internal, external, channel

1) Max frequency depends on selected waveform.

Modulation
