Continuous or internally triggered timing characteristics
81150A 81160A
Delay
Fix delay
Variable delay Out 1, 2
(1)
Range in continuous mode (2)
Range in internally triggered mode (3)
Resolution
Accuracy
Trigger Out 1, 2 to Main Out 1, 2
0 ns typ.
Independent for Out 1, Out 2
0 to 1 waveform period
0 s to 1000 s typ.
1 ps, 6 digits
± 25 ps ± 50 ppm Sync Out A, B to Main Out 1,2
0 ns typ.
Independent for Out 1, Out 2
0 to 1 waveform period
0 s to 1000 s spec.
1 ps, 6 digits
± 35 ps ± 50 ppm
Delay
Advanced mode: burst Trigger Out 1, 2 to Strobe Out 1, 2
0 ns typ. Sync Out A to Sync Out B
0 ns typ.
Jitter (4) Jitter
Main Out 1, 2 to Main Out 1, 2: 7 ps RMS typ.
Trigger Out 1, 2 to Main Out 1, 2: 8 ps RMS typ.
Trigger Out 1, 2 to Strobe Out 1, 2: 9 ps RMS typ.
Trigger Out 1, 2 to Trigger Out 1, 2: 9 ps RMS typ. Jitter
Main Out 1, 2 to Main Out 1, 2: 7 ps RMS typ.
Sync Out A, B to Main Out 1, 2: 8 ps RMS typ.
Sync Out A to Sync Out B: 9 ps RMS typ.
1) Not available, if sweep or modulation is selected.
2) Advanced mode = off or advanced mode = burst .
3) Trigger period ≥ variable delay.
4) Measured with 50 Ω source impedance at Main Out. Valid for continuous or internally triggered pulse, square, sine, ramp, arb.
Internally triggered or continuous noise or sweep has peak-peak jitter of 8 ns typ. for the 81150A and 3.2 ns for the 81160A.
Coupled mode on timing characteristics
81150A 81160A
Delay: Main Out 1 to Main Out 2
Fix delay
Variable delay Out 1, 2 (1)
Range in continuous mode (2)
Range in internally triggered mode (3)
Resolution
Accuracy
0 ns typ.
Independent for Out 1, Out 2
0 to 1 waveform period
0 s to 1000 s typ.
1 ps, 6 digits
± 25 ps ± 50 ppm
0 ns typ.
Independent for Out 1, Out 2
0 to 1 waveform period
0 s to 1000 s spec.
1 ps, 6 digits
± 35 ps ± 50 ppm
1) Not available, if sweep or modulation is selected.
2) Advanced mode = off or advanced mode = burst .
3) Trigger period ≥ variable delay.
