55 745-814-B0-001, Rev. A
Alpha MIB Parameters
Parameter Local Port/
CIB Variable
Description Access
Type
Value
atiMgntSys
1.3.6.1.4.1.926.1.3.2.0
SOFTWARE DOWNLOAD
atiMgmtSysDownload
1.3.6.1.4.1.926.1.3.2.1.0
atiMgmtSysDownloadTftpAddress
1.3.6.1.4.1.926.1.3.2.1.1.0
[Text] DOWN IP TFTP Server Address Read/Write
IP address
0.0.0.0 (default)
atiMgmtSysDownloadCtrl
1.3.6.1.4.1.926.1.3.2.1.2.0
[Discretes] GET NEW
DSM Firmware Download
“Trigger”
Read/Write
Integer
0 = Idle (default)
1 = Download File1 (From v1.08
and higher)
2 = Download File2 then File1
(From v1.05 only)
atiMgmtSysDownloadStatus
1.3.6.1.4.1.926.1.3.2.1.3.0
[Text] DOWN STAT DSM Firmware download
Status
Read Only
Integer
1=Idle (default)
2=Ready
3=Request
4=Requested
5=Transferring
6=Testing
7=DataDone
8=Error
9=Closing
atiMgmtSysDownloadFile1
1.3.6.1.4.1.926.1.3.2.1.4.0
[Text] DOWN NAME 1 DSM Firmware Filename Read/Write
Octet String
“DSM firmware filename (v1.08
and higher)
“”Loadcode.s19* (v1.05)”
atiMgmtSysDownloadFile2
1.3.6.1.4.1.926.1.3.2.1.5.0
[Text] DOWN NAME 2 Reserved Read/Write
Octet String
DSM firmware filename* (v1.05
only)
atiMgmtSysDownloadProgress
1.3.6.1.4.1.926.1.3.2.1.6.0
Download Progress in
Bytes
Read Only
Integer
0:0..100000
atiMgmtSysDownloadSysDescr
1.3.6.1.4.1.926.1.3.2.1.7.0
DSM Firmware
description used for
upgrades
Read/Write
Octet String
e.g. “ATI P01V01.12.0 “
atiMgmtSysDownloadSysObjectId
1.3.6.1.4.1.926.1.3.2.1.8.0
DSM Hardware Identifier
used for upgrades
Read/Write
Object Identifier
1.3.6.1.4.1.926.1.99.1.1.1.0
atiMgmtSysDownloadConfigName
1.3.6.1.4.1.926.1.3.2.1.9.0
[Text] DOWN CFG DSM Setup File Filename Read/Write
Octet String
atidoc01.cfg
atiMgmtSysDownloadConfigAddress
1.3.6.1.4.1.926.1.3.2.1.10.0
[Text] DOWN CFG IP DSM Setup File TFTP
loaction
Read/Write
IP address
0.0.0.0 (default)
atiMgmtSysDownloadCm
1.3.6.1.4.1.926.1.3.2.1.11.0
Force DSM Download
from modem’s
docsDevSwServerIp
(Dual IP)
Read/Write
Integer
1=Auto (default)
2=ForceCM
atiMgmtSysDownloadCfgCheckProgress
1.3.6.1.4.1.926.1.3.2.1.12.0
DSM Setup File Marker Read Only
Integer
3
10.0 MIB Parameter Definitions and Settings, continued
10.1 Alpha MIB Parameter Definitions and Settings, continued
