3.4.2 Example of an atidoc01.cfg DSM Setup File
Below is an example DSM Setup File with the following settings:
Example DSM Setup File Parameters and Values
Parameter
Type
Description
Value
atiMgmtSysDownloadCfgCheckProgress
OID: 1.3.6.1.4.1.926.1.3.2.1.12.0
Integer
Required file marker entry
3
atiMgntSnmpTrapAddress1
OID: 1.3.6.1.4.1.926.1.3.1.1.
IP address
Optional SNMP trap destination address
10.80.0.2
atiMgntSnmpTrapAddress2
OID: 1.3.6.1.4.1.926.1.3.1.1.
IP address
Optional SNMP trap destination address
70.45.94.130
atiCibDiscValue.sys.1.6
OID: 1.3.6.1.4.1.926.1.2.1.1.1.5.14.1.6
Integer
Sets XP-DSM into Dual IP Mode
1 = single IP (default)
0 = dual IP
atiMgmtSnmpSnmpv1Access
OID: 1.3.6.1.4.1.926.1.3.1.3.1.0
Integer
Required to allow remote SNMPv1 access to
power supply data
1 = disable
2 = enable (default)
atiMgmtSnmpSnmpv2Access
OID: 1.3.6.1.4.1.926.1.3.1.3.2.0
Integer
Required to allow remote SNMPv2 access to
power supply data
1 = disable
2 = enable (default)
atiMgmtSysHttpAccess
OID
:
1.3.6.1.4.1.926.1.3.2.2.1.0
Integer
Enables embedded HTTP Web server to allow
XP-DSM data to be visible from Internet Web
browser.
1 = disable
2 = enable (default)
Firmware Download
atiMgmtSysDownloadTftpAddress
OID: 1.3.6.1.4.1.926.1.3.2.1.1.0
IP address
Address of modem’s TFTP server
10.20.13.3
atiMgmtSysDownloadFile1
OID: 1.3.6.1.4.1.926.1.3.2.1.4.0
Filename
Firmware filename
esm1100_.phy
atiMgmtSysDownloadCtrl
OID: 1.3.6.1.4.1.926.1.3.2.1.2.0
Integer
“Trigger” file initiates firmware upgrade
1
See
for complete parameter definitions.
Table 3-3, Example DSM Setup File Parameters and Values
File: atidoc01.cfg
Network Access Control (3) [Len - 1]: 1
SNMP MIB Object (11) [Len = 23]: atiMgmtSysDownloadCfgCheckProgress.0 / 3
SNMP MIB Object (11) [Len = 24]: atiMgntSnmpTrapAddress1 / 10.80.0.2
SNMP MIB Object (11) [Len = 24]: atiMgntSnmpTrapAddress2 / 70.45.94.130
SNMP MIB Object (11) [Len = 26]: atiCibDiscValue.sys.1.6 / 1
SNMP MIB Object (11) [Len = 23]: atiMgmtSnmpSnmpv1Access.0 / 2
SNMP MIB Object (11) [Len = 23]: atiMgmtSnmpSnmpv2Access 0 / 2
SNMP MIB Object (11) [Len = 23]: atiMgmtSysHttpAccess 0 / 2
SNMP MIB Object (11) [Len = 23]: atiMgmtSysDownloadTftpAddress.0 / 10.20.13.3
SNMP MIB Object (11) [Len = 31]: atiMgmtSysDownloadFile1.0 / “esm1100_.phy”
SNMP MIB Object (11) [Len = 23]: atiMgmtSysDownloadCtrl.0 / 1
