45 745-814-B0-001, Rev. A
Disconnect
Captive Screws
7.0 Hardware Installation, continued
7.2 Hardware Installation Procedure
1. Switch OFF the power supply’s battery breaker.
2. Unplug all inverter module connections (e.g. battery cable, remote temperature sensor).
3. Loosen the inverter module thumbscrews and slide the inverter module out just enough
to disconnect the ribbon cable. Disconnect the ribbon cable.
4. Slide the inverter module out of the power supply.
5. If the inverter module is equipped with a communication module, remove it by loosening
the two Phillips captive screws.
Fig. 7-1, Removing the Inverter Module from the Power Supply
NOTE:
With the battery breaker in the OFF position, the power supply will not go into inverter mode.
