26 745-814-B0-001, Rev. A
5.0 Upgrading Firmware, continued
5.2 Upgrading XP-DSM Transponder Firmware
There are three methods to upgrade XP-DSM firmware: manually setting SNMP parameters
remotely in a MIB browser, setting them through the local port (see Section 4.0 ), and
automatically in the DSM Setup File (to build a Setup File, see Section 3.4 ). Once the
firmware download process has been initiated the XP-DSM will download the DSM firmware
from the specified TFTP server. The XP-DSM remains fully functional during the upgrading
process and will automatically reset when the upgrade is finished.
The most recent firmware version files are available at
www.Alpha.com>Broadband>Status
Monitoring>DSM>XP-DSM Tech. Support .
XP-DSM Firmware Upgrade Parameters
Parameter Local Port
Parameter
Type Value
atiMgntSysDownload
OID: 1.3.6.1.4.1.926.1.3.2.1
atiMgmtSysDownloadTftpAddress
OID: 1.3.6.1.4.1.926.1.3.2.1.1
[Text]
DOWN IP
IP address The IP address of the modem’s TFTP server
from which the firmware will be downloaded.
atiMgmtSysDownloadCtrl
OID: 1.3.6.1.4.1.926.1.3.2.1.2
[Discrete] GET
NEW IMAGE
Integer 1 = Initiate Download of firmware file
2 = Initiate Download of two firmware files (ver-
sion 1.05.0)
3 = Idle
atiMgmtSysDownloadStatus
OID: 1.3.6.1.4.1.926.1.3.2.1.3
[Text]
DOWN STAT
Read Only
Integer
1 = Idle
5 = Transferring
6 = Testing
8 = Error
atiMgmtSysDownloadFile1
1.3.6.1.4.1.926.1.3.2.1.4
[Text]
DOWN NAME 1
Octet String Set to the filename of the firmware file
downloaded from the Alpha Website.
atiMgmtSysDownloadProgress
OID: 1.3.6.1.4.1.926.1.3.2.1.6
Integer Byte count of firmware download process.
atiMgmtSysDownloadSysDescr
OID: 1.3.6.1.4.1.926.1.3.2.1.7
Octet String Firmware version. Alpha will provide this value
with released firmware.
atiMgmtSysDownloadSysObjectID
OID: 1.3.6.1.4.1.926.1.3.2.1.8
OID 1.3.6.1.4.1.926.1.99.1.1.1 (OID embedded in
transponder to ensure firmware compatibility.)
atiMgmtSysDownloadCfgCheckProgress
OID: 1.3.6.1.4.1.926.1.3.2.1.12
Integer 3 (file maker, only used with DSM Setup File.)
Table 5-2, Transponder Firmware Upgrade SNMP Parameters
See Section 10.0 for complete parameter definitions.
NOTE:
By using a DSM Setup File, all the transponders on a network can be automatically upgraded in only one step
(see Section 3.4 ).
NOTE:
The procedures in this section presuppose firmware version 1.08.0 or newer. For an application to upgrade
from earlier firmware versions, go to www.Alpha.com>Broadband>Status Monitoring>DSM>XP-DSM Tech.
Support .
