23 745-814-B0-001, Rev. A
4.0 Using the Local Port, continued
Variables are added and moved between
firmware versions; therefore, the index values
may change from the examples. Obtain the
index value from the current displayed table
prior to updating any values.
>ana
ANALOGS
DEV-A IX NAME VALUE ENM/UNIT SET
----------------------------------------------
BSS-1 00 BATT 1A 0.00 VDC NO
BSS-1 01 BATT 2A 0.00 VDC NO
BSS-1 02 BATT 3A 0.00 VDC NO
BSS-1 03 BATT 4A 0.00 VDC NO
BSS-1 04 BATT 1B OR 5A 0.00 VDC NO
BSS-1 05 BATT 2B OR 6A 0.00 VDC NO
BSS-1 06 BATT 3B OR 7A 0.00 VDC NO
BSS-1 07 BATT 4B OR 8A 0.00 VDC NO
----------------------------------------------
XM2-1 00 INPUT VOLTAGE 118.80 Vac NO
XM2-1 01 INPUT FREQ 60.00 Hz NO
XM2-1 02 OUTPUT VOLTAGE 64.00 Vac NO
XM2-1 03 OUTPUT 1 CURR 0.00 A NO
XM2-1 04 OUTPUT 2 CURR 0.00 A NO
XM2-1 05 PERCENT LOAD 0.00 % NO
XM2-1 06 OUTPUT VA 0.00 VA NO
XM2-1 07 OUTPUT WATTS 0.00 W NO
XM2-1 08 BATT VOLTAGE 40.40 Vdc NO
XM2-1 09 CHARGER CURR 1.20 A NO
XM2-1 10 BATTERY TEMP 27.50 oC NO
XM2-1 11 FREQ RANGE 3.00 Hz YES
XM2-1 12 FLOAT V/C 2.25 YES
XM2-1 13 ACCEPT V/C 2.35 YES
XM2-1 14 TEMP COMP 3.00 mV YES
XM2-1 15 PEAK CURR 1 10.00 A YES
XM2-1 16 PEAK CURR 2 10.00 A YES
XM2-1 17 CHGR CURR LIMIT 25.50 A NO
XM2-1 18 EOD VOLTAGE V/C 1.75 YES
----------------------------------------------
SYS-1 00 INPUT CURRENT 2.30 A NO
----------------------------------------------
Analogs Table
>cou
COUNTERS
DEV-A IX NAME VALUE ENM/UNIT SET
----------------------------------------------
BSS-1 00 NUMBER OF BATTS 0 YES
BSS-1 01 NUMBER OF STRNGS 0 YES
----------------------------------------------
XM2-1 00 TEST INTERVAL 30 DAY YES
XM2-1 01 TEST COUNTDOWN 30 DAY YES
XM2-1 02 TEST DURATION 10 MIN YES
XM2-1 03 STANDBY TIME 163 MIN YES
XM2-1 04 STANDBY EVENTS 164 YES
XM2-1 05 RETRY DELAY 60 SEC YES
XM2-1 06 RETRY LIMIT 20 YES
XM2-1 07 OVER CURR TOL 3 SEC YES
XM2-1 08 BATT CAPACITY 100 AH YES
XM2-1 09 RESERVED 0 BMP NO
XM2-1 10 DEVICE ADDRESS 1 YES
XM2-1 11 TOTAL RUN TIME 496 DAY NO
----------------------------------------------
SYS-1 00 PING CYCLE TIME 10 MIN YES
SYS-1 01 POLL CYCLE TIME 10 SEC YES
SYS-1 02 POLL RETRIES 5 YES
SYS-1 03 ENGINE BOOTS HI 0 YES
SYS-1 04 ENGINE BOOTS LO 5 YES
SYS-1 05 TRAP SEND COUNT 0 YES
SYS-1 06 SNMP COM TIMEOUT 24 HR YES
SYS-1 07 RECONFIG TIMER 24 HR YES
----------------------------------------------
Counters Table
NOTE:
>tex
TEXT
----------------------------------------------
0 [ro] DHCP STATE : DISCOVER SENT
1 [ro] DHCP TIMER : 0
2 [ro] DHCP SERV : 0.0.0.0
3 [ro] DHCP SERV 54 : 0.0.0.0
4 [ro] DOWN STAT :
5 [rw] DOWN NAME 1 :
6 [rw] DOWN NAME 2 :
7 [rw] DOWN IP : 0.0.0.0
8 [rw] DOWN CFG :
9 [rw] DOWN CFG IP : 0.0.0.0
10 [rw] NTP SERV : 0.0.0.0
11 [ro] NTP DHCP : 0.0.0.0
12 [ro] NTP TIME UTC : 01/01/70 00:00:00
13 [ro] ENET ADDR : 00.90.EA.A0.1E.5F
14 [ro] IP ADDR IN USE : 0.0.0.0
15 [ro] NETMASK IN USE : 0.0.0.0
16 [ro] GATEWAY IN USE : 0.0.0.0
17 [rw] IP ADDR STATIC : 0.0.0.0
18 [rw] NETMASK STATIC : 0.0.0.0
19 [rw] GATEWAY STATIC : 0.0.0.0
20 [rw] SNMP TRAP TARGET : 0.0.0.0
21 [rw] SNMP TRAP TARGET : 0.0.0.0
22 [rw] SNMP TRAP TARGET : 0.0.0.0
23 [rw] SNMP TRAP TARGET : 0.0.0.0
24 [rw] SNMP ACCESS LIST : 0.0.0.0
25 [rw] SNMP ACCESS LIST : 0.0.0.0
26 [rw] SNMP ACCESS LIST : 0.0.0.0
27 [rw] SNMP ACCESS LIST : 0.0.0.0
28 [ro] sysDescr : ATI P01V1.08.0
29 [rw] sysName :
30 [rw] sysContact :
31 [rw] sysLocation :
32 [rw] comLogicalID :
33 [ro] CHECK CODE : 146.51.132.199
34 [rw] PING IP : 0.0.0.0
35 [rw] ATICONFIG IP : 0.0.0.0
36 [rw] ATICONFIG NAME :
37 [ro] TIME UP : 0 00:00:29
38 [ro] CM/RF ENET : 00.03.08.0B.9A.EA
39 [ro] CM IP : 192.168.1.192
40 [ro] CM SUBNET : 255.255.255.0
41 [ro] CM GATEWAY : 192.168.1.1
42 [ro] CM TOD : 192.43.244.18
43 [ro] CM TFTP : 192.168.1.51
44 [rw] SNMP GET : AlphaGet
45 [rw] SNMP SET : AlphaSet
46 [rw] SNMP TRAP : public
47 [rw] ALPHA SNMP SETS : CIBSET
---------------------------------------------
Text Table
Note: no subsystem
