49

745-814-B0-001, Rev. A

8.0 Battery Sense Wire Kit Connections

8.1 36V Single and Dual Strings

POS

POS

POS

Back of Plug

Fig. 8-1, 36V System, Single String

Alpha P/N: 874-842-21 (6')

Alpha P/N: 874-842-27 (9')

1

2

3

4

5

6

7

8

Vbatt 3A

[C] 36V

Pin 4

3A

POS

NEG

2A

POS

NEG

1A

POS

NEG

A/B [C/D] NEG

Pin 1

Vbatt 2A

[C] 24V

Pin 3

Vbatt 1A

[C] 12V

Pin 2

To Power Supply

Fig. 8-2, 36V System, Dual String

Alpha P/N: 874-842-20 (6')

Alpha P/N: 874-842-28 (9')

3B

NEG

2B

NEG

1B

NEG

1

2

3

4

5

6

7

8

Back of Plug

3A

POS

NEG

2A

POS

NEG

1A

POS

NEG

A/B [C/D] NEG

Pin 1

Vbatt 3A

[C] 36V

Pin 4

Vbatt 2A

[C] 24V

Pin 3

Vbatt 1A

[C] 12V

Pin 2

Vbatt 3B [D] 36V

Pin 7

Vbatt 2B [D] 24V

Pin 6

Vbatt 1B [D] 12V

Pin 5

To Power Supply

Black

Red

Red

Black
