6.0 Data Management, continued
6.3
SCTE-HMS MIB Alarms, continued
6.3.1 SCTE-HMS Configurable Alarms, continued
Table 6-4, Analog Alarms and Common Settings
Analog Alarms and Common Settings
Analog Alarms Description
Alarm
Enable LOLO
LO HI HIHI Deadband
psTotalStringVoltage 36V Scaled representation of the full
battery string in 1/100 Volts units
0x0F 3120 3140 4510 4530 .1V
48V 0x0F 4160 4185 6015 6040 .1V
psBatteryVoltage Battery Voltage of 12V battery,
scaled 1/100 V
0x0F 970 1000 1530 1550 .1V
psInputVoltage 120V Scaled representation of the
input line voltage in 1/100 Volts
units
0x0F Varies by site. The XM2 will switch to standby at
Nominal +15% -20%
220V 0x0F
psOutputVoltage 48V Scaled representation of the
power supply output voltage in
1/100 Volts units.
0x0F 4300 4550 5050 5300 1V
60V 0x0F 5650 6000 6600 7000 1V
90V 0x0F 7830 8265 9135 9570 1V
psPowerOut Representation of power supply
output power in 1W
0x00 Monitor Output Current Instead
psStringChargeCurrent Battery string charge current,
scaled at 1/100 Amp
0x0C Disable Disable 1200 1250 0.2A
psStringFloat Battery string float charge
current, scaled at 1/100 Amp
0x0C Disable Disable 1200 1250 0.2A
psStringDischargeCurrent Battery string discharge current,
scaled at 1/100 Amp
0x00 Not Supported by XM2/GMX
psOutputCurrent 15A Scaled representation of power
supply RMS current in 1/100
Amp units
0x0C Disable Disable 1725 1875 0.2A
22A 0x0C Disable Disable 2530 2750 0.2A
psTemperature -40 to +80 degrees C 0x0F Varies by site
The following table displays the various analog alarms with common settings.
