8.0 Specifi cations
General Speci cations
General
Model:
XP-EDH-A2
Power Supplies Supported:
XM2 (requires USM2 or USM2.5)
XM (requires USM)
Lectro ZTT, ZTT+
AM (requires APM card)
DOCSIS Compatibility
0
Monitoring Protocol:
SNMPv1
RF Transmit/Receive
Tx Frequency Range:
5 to 42MHz
Output Power:
8 to 55dBmV
Channel Bandwidth:
6MHz
Receive Center Freq Range:
91 to 857MHz (Standard, HRC, IRC channels)
Input Level:
-15 to +15dBmV
Monitored Parameters
Power Supply Data
One to three of 36V or 48V
Battery Data:
Individual Battery Voltages
Battery Compartment Temperature
Hardware
RF Cable Interface:
F-connector, female, 75Ohm
LED Indicators:
CMTS Registration
Upstream Activity
Downstream Activity
Unit Power
Environmental:
-40 to 65˚C
10 to 90% non-condensing humidity
Emissions:
EN50022 Class A and FCC Part 15 Class A
(Installed in power supply enclosure system)
Immunity:
Surge Test per Speci
ion (IEEE C62.41-1991)
ESD Protection: ±8kV air discharge, ±6kV contact
discharge as per (IEC 61000-4-2)
Warranty:
2 years
Dimensi ons (in):
5.2D x 8.6W x 1.3H
Management
NMS/EMS:
• Standard SNMP Management Tools
HMS MIBs:
In addition to the standard DOCSIS MIBs, the transponder
supports the following HMS MIBs:
SCTE 25-3 (HMS-022):
Interface
SCTE 36 (HMS-050):
Root
MIB SCTE 37 (HMS-072):
Tree
MIB SCTE 38-1 (HMS-026):
Property
MIB SCTE 38-2 (HMS-023):
Alarm MIB
SCTE 38-3 (HMS-024):
Common
MIB SCTE 38-4 (HMS-027):
Power Supply
MIB SCTE 38-6 (HMS-033):
Generator
MIB SCTE 38-7 (HMS-050):
TIB MIB
Ordering Information
Model Number
Description
XP-EDH-A
A
r
CBL-PS-INT-01-003
Interface cable, XM, XM2 power supplies
CBL-PS-INT-01-002
Interface cable, AM/AP power supply
CBL-PS-INT-02-005
Interface cable, Lectro ZTT, ZTT+ power supplies
CBL-PS-PWR-01-001
Line voltage cable, XM, XM2, AM/AP, 120V
CBL-PS-PWR-03-002
Line voltage cable: XM, XM2, AM/AP, 220V
CBL-PS-PWR-02-002
Line voltage cable, Lectro 120VAC
CBL-PS-PWR-04-001
Line voltage cable, Lectro 220VAC
CBL-PS-BAT-04-004
Wire Kit, Battery Sense, 1x36V or 1x48V, 4’
CBL-PS-BAT-06-004
Wire Kit, Battery Sense, 2x36V, 4’
CBL-PS-BAT-08-004
Wire Kit, Battery Sense, 2x48V, 4’
CBL-PS-BAT-12-004
Wire Kit, Battery Sense, 3x48V, 4’
ZTT Series
Major Alarm:
X
X X
X
Minor Alarm:
X
X X
X
Input Line Voltage:
X
X
1
X
1
X
1
Output Voltage:
X
X X
X
1
Battery Voltage:
X
X X
X
Output Current:
X
X X
X
1
Standby/AC Line Fail:
X
X X
X
Equipment/Test Fail:
X
X X
Enclosure Door Status:
X
X X
X
Remote Test Control:
X
X X
X
Notes:
1 Requires optional cable assembly
Local Port Interface
USB Type B
XM2
Model:
XM AM
Number of Battery Strings:
2
External DOCSIS Transponde
lphaNet
* Other Battery Sense Wire Kits available
; contact Alpha for more information
SNMPv2c
,
:
DOCSIS 2.
