13 745-838-B2-001 Rev. A
2.1.10 Verifying Operation
After the connections are complete and the transponder’s online LED is on solid, •
indicating network connectivity, verify the site is visible on the appropriate cable
modem or computer network, and that all parameters being monitored are visible
and accurate.
Any standard Web browser on a personal computer confi gured for network •
connectivity to the transponder should be able to read the XP-EDH-A2
Web interface by simply pointing the Web browser to the IP address of the
transponder (for example, http://10.1.3.65).
Confi rm that all cable harnesses are neatly dressed within the enclosure. •
Verify that you can close the cabinet door, and move the battery tray in and out, •
without contacting or damaging any of the cables.
Sets Read-Write
Community string. Set
the IP addresses and
community strings to fi t
your system.
Sets Read-Only
Community string. Set
the IP addresses and
community strings to fi t
your system.
Sets fi rmware
download parameters.
Sets Code Verifi cation
Certifi cate (CVC)
SNMP MIB Object (11) [Len=21]:docsDevNmAccessStatus.1/4
SNMP MIB Object (11) [Len=21]:docsDevNmAccesslp.1/192.168.1.0
SNMP MIB Object (11) [Len=21]:docsDevNmAccesslpMask.1/255.255.255.0
SNMP MIB Object (11) [Len=25]:docsDevNmAccessCommunity.1/"RWRWRWRW"
SNMP MIB Object (11) [Len=21]:docsDevNmAccessControl.1/3
SNMP MIB Object (11) [Len=21]:docsDevNmAccessStatus.2/4
SNMP MIB Object (11) [Len=21]:docsDevNmAccesslp.2/192.168.1.0
SNMP MIB Object (11) [Len=21]:docsDevNmAccesslpMask.2/255.255.255.0
SNMP MIB Object (11) [Len=25]:docsDevNmAccessCommunity.2/"RORORORO"
SNMP MIB Object (11) [Len=21]:docsDevNmAccessControl.2/2
Software Upgrade Filename(9) [Len=24]:" MODEM_Firmware_file.bin”
SNMP MIB Object (11) [Len=20]:docsDevSwAdminStatus.0/2
Software Upgrade TFTP Server (21) [Len=4]:192.168.1.51
Manufacturer Code Verification Certificate (32) [Len=254]: 30 82 03 1A 30 82...
Manufacturer Code Verification Certificate (32) [Len=254]: 04 0A 13 11 41 4D...
Manufacturer Code Verification Certificate (32) [Len=254]: 04 0C 30 0A 06 01...
Manufacturer Code Verification Certificate (32) [Len=36]: 11 A3 41 A6 A7 D9....
2.0 Installation, continued
2.1 General Installation Information for Supported Power Supplies, continued
2.1.9 Setting the DOCSIS Confi guration File Options
This step is performed at the network end of the installation. •
This fi le supplies the security and community string settings for the system, as •
well as the software upgrade parameters. Set the community strings, matching
your DOCSIS cable modems. The following is an example:
