31 745-838-B2-001 Rev. A
4.0 Proprietary Management Information Bases (MIBs)
You need to use two proprietary MIBs to successfully confi gure the XP-EDH-A2 to use the power
supplies described in this manual. Compile these two MIBs onto a network manager or MIB browser
software.
To see a specifi c example of a MIBs fi le for a particular power supply, see that section of the manual.
The objects available are:
Object Description
amDocsisDevicesTable
Oid: 1.3.6.1.4.1.2183.2.3.3.1.2
Set to the type of supply being monitored:
alphaXM2 (2) default
alphaXM (3)
alphaAM/AP (4)
lectroSentryII (5)
lectroZTT (6)
lectroZTTPlus (7)
amDocsisOPVoltageScaling
Oid: 1.3.6.1.4.1.2183.2.3.6.5
Set to 4 with Alpha XM2 type supplies using USM2 or USM2.5 cards.
Set to 4 with Alpha XM type supplies using USM cards.
Set to 3 for legacy power supplies (AM/AP, Lectro ZTT, ZTT+).
amDocsisInputVoltageMeasScaling
Oid: 1.3.6.1.4.1.2183.2.3.6.6
Set to 1 (default) for 110V powered supplies (Alpha or Lectro).
Set to 2 for 220V powered supplies (Alpha or Lectro).
Note: Presently this object is used in conjunction with Alpha’s 110V or
220V wall/brick transformers to sample the input line voltage.
The scaled voltage available in the Alpha USM2.5 cards report the
input line voltage.
Table 4-1, Proprietary MIBs
