6.0 Cable Selection Guide
XM , XM2 power supplies
Interface cables :
CBL-PS-INTFC-01-003
AM / AP power supplies
CBL-PS-INTRFC-01-002
CBL-PS-INTFC-01-003
HOT
NEU
T
CBL-PS-INTFC-01-002
ZTT
Z TT+
Z TT+ SI L V ER
GR OU ND
TAM PER
BL
A C K
3 POSITION
Lectro ZTT & ZTT+ power supplies
CBL-PS-INTFC-02-005
SWITCH
CBL-PS-INTFC-02-005
(Alpha P/N 875-565-10)
(Alpha P/N 875-564-10)
(Alpha P/N 875-566-10)
