7.0 Dimensions and Specifi cations
7.1 Dimensions of XP-EDH-A2
Fig. 7-1, Outline Dimensions, XP-EDH-A2
4.55"
9.42"
(overall)
1.26"
1.26"
8.75"
Alpha P/N: 745-838-10-004 Model No: XP-EDH-A22
MAC ID: XXXXXXXXXXXX S/N: XXXXXXXX
Attention
This transponder measures scaled AC
•
output voltage.
Verify the XM-USM or XM2-USM2/USM2.5
•
is confi gured for scaled AC output.
