3. Specifi cations

3.4

7.2Ah and 17Ah Battery Modules

These specifi cations apply to confi gurations incorporating 30W Home Converters and Power
Converters.

AX-12D-BBPS-7.2

AX-12D-BBPS-17

Input

Voltage

DC input from Power-Ring or Home Converter

(See Section "2.0 Applications" for maximum

length of interconnecting wire)

DC input from Power-Ring or Home Converter

(See Section "2.0 Applications" for maximum

length of interconnecting wire)

Interface

3 position terminal strip or connector suitable for

accepting #14 to #20AWG wire.

3 position terminal strip or connector suitable for

accepting #14 to #20AWG wire

Output

Power Capability

30W continuous

45W max. (<10s)

30W continuous (see Note 1)

45W max., <10s

Voltage

10.5 to 14.4Vdc

10.5 to 14.4Vdc

Number of Outputs

1

1

Frequency

DC

DC

Transient Response

Not to exceed 1s

Not to exceed 1s

Ripple Voltage, Maximum

150mV

150mV

Nominal System Effi ciency

77%

>77%

Output Grounding

Floating, SELV

Floating, SELV

Short Circuit Protection

Electronic

Electronic

Overload Protection

Integral

Integral

Interface

7 position terminal strip or connector suitable

for accepting #18 to 22AWG wire carrying 12V

and PacketCable alarms

7 position terminal strip or connector suitable

for accepting #18 to 22AWG wire carrying 12V

and PacketCable alarms

Charging

Voltage

12Vdc nominal

12Vdc nominal

Charge Current

1.8A maximum

Unlimited within the power supply rating

Typical Recharge Time

12 Hours @ 24 Watt load

12 hours @ 17 Watt load

<36 hours @ 24 Watt load

Charge Voltage Temp. Comp. Range

-10°C to +40°C (14ºF to 104ºF)

-10°C to +40°C (14ºF to 104ºF)

Charge Compensation Voltage

20mV/°C

20mV/°C

Charge Voltage, Float

13.65V @ 25°C (77ºF)

13.65V @ 25°C (77ºF)

Charge Voltage, Accept

14.40V @ 25°C (77ºF)

14.40V @ 25°C (77ºF)

EOD Voltage before battery disconnection

Less than or equal to 10.5 Vdc for

a minimum of 5s

Less than or equal to 10.5 Vdc for

a minimum of 5s

Quiescent Current

< 5mA after EOD

< 5mA after EOD

Battery Grounding

Float, SELV

Float, SELV

Battery Type

AGM Valve-Regulated Lead Acid

AGM Valve-Regulated Lead Acid

Battery Capacity

7.2Ah

17Ah

Quantity

1

1

Battery Heater

Integral—operation to -40°C

Integral—operation to -40°C

Alarms

Packet Cable

AC Line Fail, No Battery, Replace Battery,

Low/missing Battery, Replace Battery

(all signals isolated from output)

AC Line Fail, No Battery, Replace Battery,

Low/missing Battery, Replace Battery

(all signals isolated from output)

LEDs

Above alarm conditions indicated by LEDs

Above alarm conditions indicated by LEDs

Note 1: Due to the temperature differences between indoor and outdoor devices, Alpha recommends a

maximum continuous load of 24W if an indoor home converter (AX30-12-HC) is used with a battery
module located outside.
