FlexPoint AX Module

AX30-12D-PC or HC

with AX-12D-BBPS-7.2

AX30-12D-PC or HC

with AX-12D-BBPS-17

Input

AC Input Voltage (120)

85/132

AC Input Voltage (230)

170/264

AC Input Frequency

50/60Hz

Output

DC Output Voltage

10.5 to 14.4

Continuous Output Power

30W at nominal battery fl oat voltage

Maximum Output Power (<10s)

45W (when used in conjunction with Battery Box)

Short Circuit Protection

Electronic

Ripple Voltage, Maximum

150mVrms with battery

Nominal Effi ciency (at 75% max load)

75%

Environment

Operating Temperature Range

-40°F to +149°F/-40°C to +65°C, 0 to 95% humidity

Battery Storage:

+5°F to +149°F/-15°C to +65°C, 0 to 95% humidity

Battery

Type

Maintenance free, leak-proof, sealed VRLA (valve regulated lead acid)

Recharge time

12 Hours with 24W load

36 Hours with 24W load

Status Alarms–Local (LED Indicators)

Green Steady

Output OK

Green Blinking

Standby Operation

Red Steady

Replace Battery

Red Blinking

Battery Missing/Battery Low

Status Alarms–Remote

AC Fail

Output Power drawn from battery

Replace Battery

Battery has failed periodic self test

Battery Missing

Battery is disconnected

Battery Low

Indicates battery has 20% remaining runtime available

Regulatory Approvals

Home Converter

UL Listed System, FCC Part 15, Class B, EN55022, Class B

Power Ring

UL Recognized Components

Power Ring Converter

UL Recognized Components

Battery Box

CSA, CENELEC

CSA

Warranty

Electronics

2 years

Battery–Standard

1 years

Battery–Long Life

3 years

3.1 System

Specifi cations, Power Supply and Battery Box

FlexPoint AX UPS Typical Runtimes (minutes)

7.2Ah

17Ah

Temperature

Temperature

°F/°C

-40/-40

-4/-20

77/25

°F/°C

-40/-40

-4/20

77/25

Load (W)

Time (Minutes)

Load (W)

Time (Minutes)

4

820

1100

1200

10

750

1080

1240

7

360

560

800

15

400

680

940

10

160

360

500

20

260

440

680

15

80

195

320

25

160

340

480

18

N/A

156

240

30

140

232

400

3. Specifi cations
