background image

15

010-318-C0-007, Rev. G

3. Specifi cations

3.2 Power-Ring

Converter

AX30-12D-PC

Input

Vmin

170

Vmax

264

Frequency

50/60Hz

Frequency Tolerance

±10%

Acceptable Source Imp.

<5% FL equivalent impedance

Max Current Limit

1.6A

Power Factor

.60

Max Surge Current

10A RMS

Protection

Fuse, MOV

Interface

Side Slide Pressured contacts for input power.

Surge Resistance

IEEE Std. C62.41-1991 level C

Output Voltage Control
(for use with battery module)

5Vdc. 5mA DC Max

Output

Power Capability

30W continuous (if used with battery box)

24W continuous (if used in standalone confi guration)

Voltage

12 Vdc nominal

(11.6 to 16Vdc auto-adjust if used with battery box)

Number of Outputs

1

Startup Overshoot Voltage

<120% of nominal for 0.5s max

Frequency

DC

Transient Response

Not to exceed 1s

Ripple Voltage, Maximum

500mV

Nominal Effi ciency

75%

Output Grounding

Floating, SELV

Short Circuit Protection

Electronic

Overload Protection

Integral

Interface

3 position terminal strip or connector suitable for accepting #12 to

20AWG wire.

Enclosure

Material

Plastic

Mounting

Inserted inside a Meter Adapter

Color

Gray

Cooling

Natural Convection

Physical Size, approximate (in/mm)

8"L x 2"W x 2"D/209/51/51

Weight (lb/kg)

0.7/0.32

Acoustic Noise, All Modes

Not to exceed 50dBA at 1 meter.

Environmental

Temperature —UL Rated

-40°C to +65°C @ 30W load

Humidity

5% to 95%

Altitude

> 5K feet, derate max. temp by 2°C per additional 1K feet

Location

Outdoors, all environmental conditions

Reliability

Telcordia Reliability Prediction

> 200,000 hours

15% of life @ 50ºC, 2% of life @t 60ºC

Agency Compliance

EMC

FCC Part 15, Class B

Safety: Mark

USR, CNR

Standard

UL60950

ROHS
