16 010-318-C0-007, Rev. G
3.3 Home Converter
AX30-12D-HC
Input
Vmin 85/170 Selectable (when ordered)
Vmax 132/264 Selectable (when ordered)
Frequency 50/60Hz
Frequency Tolerance ±10%
Acceptable Source Imp. <5% FL equivalent impedance
Max Current Limit 1.6A
Power Factor .60
Max Surge Current 10A RMS
Protection Fuse, MOV
Interface Hard-Wired AC Line Cord
Surge Resistance IEEE Std. C62.41-1991 level C
Output Voltage Control
(for use with battery module)
5Vdc. 5mA DC Max
Output
Power Capability
30W continuous (if used with battery box)
24 W continuous if used in standalone confi guration)
Voltage 12Vdc Nominal
Number of Outputs 1
Startup Overshoot Voltage <120% of nominal for 0.5s max
Frequency DC
Transient Response Not to exceed 1s
Ripple Voltage, Maximum 500mV w/o battery, 150mV with battery
Nominal Effi ciency 75%
Output Grounding Floating, SELV
Short Circuit Protection Electronic
Overload Protection Integral
Interface
3 position terminal strip or connector
suitable for accepting #12 to 20AWG wire.
Enclosure
Material Plastic
Mounting Wall-mount
Color Gray
Cooling Natural Convection
Physical Size, approximate (in/mm) 2" H x 3" W x 8.5" D/ 51 x 76 x 216
Weight (lb/kg) 1/.45
Acoustic Noise, All Modes Not to exceed 50dBA at 1 meter.
Environmental
Temperature — UL Rated: -40°C to +45°C @ 30W load
Humidity 5% to 95%
Altitude > 5K feet, derate max. temp by 2°C per additional 1K feet
Location Indoors, semi-protected, non-water-dripping environment
Reliability
Telcordia Reliability Prediction: > 200,000 hours
Agency Compliance
EMC FCC Part 15, Class B
Safety: Mark USR, CNR
Standard UL60950
CENELEC
EN55022 Class B and EN50082 Class B
ROHS
3. Specifi cations
