ABUS CASA30500 Operating instructions - Manual (Page 45)

45
English
Audio transmission power < 20 dBm
Audio sensitivity -82 dBm
Audio data rate 64 Kbps
Wireless range 30 m (depending on site conditions) *
Event log 500
Adjustable alarm tone 5 doorbell tones
Loudspeakers 8 Ohm, 2 W x 2
Microphone Integrated
Network RJ45 10/100 Mbit Ethernet
Storage medium SDHC card, max. 32 GB
Power supply 12 V DC / 1 A
Power consumption Max. 800 mA
Degree of protection IP30
Operating temperature -10 °C – 50 °C
Dimensions (W x H x D) 185 x 200 x 100
Net weight 670 g
Model number
CASA30400
Eycasa Family Care camera
Alarm VOX signal on Eycasa main unit
Connectible devices Eycasa main unit
Operating mode Permanent power supply or battery-powered
Image sensor 1/4" CMOS
Resolution 640 x 480 pixels (VGA)
Focal length 3.27 mm
Horizontal angle of view 54°
Number of IR LEDs 7 IR LEDs
Range of night vision function Approx. 3 m
IR angle 90°
IR swivel filter No
Video frequency 2.4 Ghz
Video modulation FHSS+GFSK
Video data rate 800 kbps
Video transmission power 13.5 dBm
Video sensitivity -82 dBm
Audio frequency 1.9 Ghz
Audio modulation TMDA
Audio transmission power < 20 dBm
Audio sensitivity -82 dBm
Audio data rate 64 kbps
Wireless range 30 m (depending on site conditions)
Video compression MPEG-4
Frame rate 20 fps
Microphone Integrated
VOX sensitivity 5 levels
Loudspeaker 8 ohms / 1 x 1 watt
DC power supply 5 V
Battery type 1200 mAh / 3.7 V lithium polymer battery
Rechargeable battery running
time
3 hours of continuous operation / 24 hours standby
Power consumption max. 850 mAh
IP protection class IP34
Max. operating temperature -10 °C – 50 °C
Dimensions (W x H x D) 69 x 117 x 32
Net weight 500 g
