English
6. Mounting the system components
6.1 Mounting the Eycasa main unit
The Eycasa main unit can be installed either on a table or wall. When delivered, the table mount is already
attached, allowing you to place the device wherever you would like indoors. Alternatively, the back cover of
the main unit can be replaced with the included wall mount. The following steps describe how to install the
wall mount.
1.
•Remove the table mount on the rear of the device by pushing the back cover downwards and off. Be
sure not to touch or damage electronic components while the main unit is open.
2.
Put the wall mount into the desired position on the wall and mark the drill holes. The distance between
the two holes is 102 mm.
3.
Attach the screws using wall plugs and put on the wall mount. The wall mount should be completely
screwed together only after placement onto the screw heads.
Important:
Choose the installation location of the main unit so that optimal range of all Eycasa
components is possible. Make sure that a distance of no more than 30 m (depending on the
building characteristics, this can be less) from the main unit is not exceeded. Additional walls
can reduce the wireless range. Test the range before installation.
