background image

10

English

Doorbell button

Backlit doorbell button (not in battery mode).
Backlighting switches on automatically in night mode (camera
photo sensor).

When the doorbell button is pressed, a connection to the
Eycasa main unit is established with a video image.

Microphone

Built-in microphone for two-way voice communication with
Eycasa main unit or handset.

ABUS logo

Logo can be rotated 90° with horizontal installation of the video
door station.

Proximity reader

Built-in proximity reader for use of the ABUS wireless chip key
(FUBE50020) for opening the door on the door station.
Not available in battery mode.

Connector block
(Rear)

Connector block for power and relay contacts (potential-free,
NO)
Voltage: 12

–24 V AC/DC

Relay 1 = door opener
Relay 2 = electronic chime
Not available in battery mode.

Battery compartment

Removable battery compartment for 6 x AA batteries (1.5 V).
Use CASA30150 for this.

Microphone

Two-way communication for Eycasa main unit.

Loudspeaker

Integrated loudspeaker.

Important:
The video door station is subject to limitations in battery mode to ensure the longest possible
battery life. The following functions are disabled:
proximity key, backlighting of the doorbell button, door opener function (no relay triggering),
continuous video transmission.

In battery mode, the door station operates in a power-saving mode and wakes up when the
doorbell is pressed. In this case, it takes approx. 5 seconds to establish a connection to the
main unit.

We recommend that you run the video door station on a permanent power supply to be able
to use the full functionality.
