7. System operation
7.1 Start-up of the Eycasa main unit
Sequence:
1. Connect the power supply unit to your Eycasa main unit.
2. The device starts automatically after the line voltage is present.
3. Wait until the boot process is complete.
4. During initial start-up, the system language is set after the system boots.
5. Select the language by pressing the corresponding country flag on the display.
6. Press the button twice to return to the live view.
7.2 Operating the live view
Individual image view 4x view
The Eycasa main unit has a touchscreen interface; all functions are operated by finger pressure on the
appropriate button. In the live view, the following adjustment options and displays are available:
Switching between live view and event list.
Display of the signal strength of the currently selected cameras. Note that the
signal strength may be displayed only when there is active image content. In the
4x view, this function is not available.
Manually select camera 1 to 4 for the individual image view.
Switches between individual image view and 4x view.
Button opens the system settings of the Eycasa main unit.
