English
After connecting the power supply, mount the video door station on the house wall.
The recommended installation height is 1.6 meters between the ground and camera module. Put on the
video door station at the desired location and use the screw holes on the bottom shell to mark the drill holes.
After finishing the wall mounting, put the door station back together to complete the installation.
6.3 Mounting the Eycasa outdoor camera
Use the camera mount to help you find a suitable place for installation. Use the drill holes to mark the
surface, and drill the holes. Insert the included wall plugs before you attach the mount with the screws.
You can also swivel the mount by 90° into a particular position. First loosen the screw on the side and set
the required angle. Then tighten the screw to secure the required position.
Screw the camera onto the mount and connect the power supply unit to the camera.
Important:
Only use the included antenna for installation.
