7
Dispenser-Specific Wiring
Dispenser
Breaker
ORG/BLK
ORG
BLK
WHT
Sensor
404-4 Controller
12A, 240VAC
H
N
G G
GRN/YEL
GRN
120-240VAC
1
2
3
4
5
6
7
8
9
10
11
12
Main Junction Box
W-V
Figure 7: 404-4 Wired to a 120V Dresser-Wayne Vista 3 Series Dispenser
Figure 8: 404-4 Wired to a Dresser Wayne Ovation Dispenser
Junction Box
BK W
-BK
W
-BN
BN V V Y W W-
R
Dispenser Control
Power
Line
N
ORG/BLK
ORG
BLK
WHT
Sensor
404-4 Controller
12A, 240VAC
H
N
G G
GRN/YEL GRN
120-240VAC
