About the PVT CV D
The PVT CV D is a wall or furniture mountable wall plate that fits any single opening Decora
style wall plate. It can transmit composite video and stereo audio to any PoleVault switcher.
In addition, a 2-pole IR pass-through provides control connection for IR devices.
AUDIO IN
L
R
VIDEO IN
IR OUT
S G
AUDIO IN
L
R
VIDEO IN
IR OUT
S G
Figure 1.
PVT CV D face and rear panels
About the PVT CV AAP
The PVT CV AAP fits a standard double space AAP opening and can transmit composite
video and stereo audio to the PVS switcher.
AUDIO IN
L
R
VIDEO
IN
PVT CV
Figure 2.
PVT CV AAP face and rear panels
PVT Series • Introduction
2
