PVT Series • Reference Material 16
Video input — composite video
Number/signal type ........................ 1 composite video
Connectors .................................... 1 female RCA
Nominal level ................................. 1 Vp-p for composite video
Minimum/maximum levels .............. Analog: 0.3 V to 1.5 Vp-p with no offset
Impedance ..................................... 75 ohms
Return loss ..................................... <-30 dB @ 10 MHz
DC offset (max. allowable) ............. 100 mV
Video output — composite video
Number/signal type ........................ 1 analog proprietary signal
Connectors
All models ............................... 1 female RJ-45
Sync — composite video
Standards ....................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Audio input
Number/signal type
PVT RGB D Plus ........................ 2 stereo, unbalanced: 1 input, 1 pass-through
All other models ...................... 1 stereo, unbalanced
Connectors
All RGB models ........................ (1) 3.5 mm mini audio jack (tip, ring, sleeve)
All CV models .......................... 1 pair female RCA
Impedance ..................................... >10k ohms unbalanced, AC coupled
Nominal level ................................. -10 dBV (316 mVrms)
Maximum level ............................... +11 dBu, (unbalanced) at 1% THD+N
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
Audio output to a PoleVault switcher (all models)
Number/signal type ........................ 1 analog proprietary signal
Connectors
All models ............................... 1 female RJ-45
Audio output — pass-through, PVT RGB D Plus only
Number/signal type ........................ 1 stereo, unbalanced
Connector ...................................... (1) 3.5 mm mini audio jack (tip, ring, sleeve)
Control — IR port — PVT CV D, PVT RGB D Plus,
PVT RGB D (EDID), PVT RGB AAP (EDID)
Number and connectors ................. 1 female 3.5 mm captive screw connector, 2 pole, for IR pass-through
General
Power ............................................ Supplied by a PoleVault twisted pair receiver/switcher
Power input requirements
PVT RGB D, PVT RGB AAP, PVT RGB D Plus
5.5 VDC, 0.15 A
PVT CV AAP, PVT CV D ............ 5.5 VDC, 0.11 A
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling .......................................... Convection, no vents
Mounting
Rack mount
PVT CV AAP, PVT RGB AAP Yes, with optional faceplate
Furniture or wall mount
PVT CV D, PVT RGB D, PVT RGB D Plus
Yes, with the included Decora ® wall plate
PVT CV AAP, PVT RGB AAP Yes, with optional faceplates or AAP wall plates
