Extron RGB 302/304 Universal Interface • User’s Manual
Appendix A • Programmer’s Guide
Page A-4
Commands ASCII Hex Response
Set Fade To Black
Fade Screen B 42 Blk 1
↵
Clear Fade To Black
Fade Screen b 62 Blk 0
↵
Unit Reset
Reset Unit Esc P 99
↵
1B+50+39+39 Updated
↵
Query Software Version
Q/q 51/71 QVER
↵
Request Part Number
N/n 4E/6E N60-243-01
↵
(for RGB 302)
N60-244-01
↵
(for RGB 304)
Request Information
I/i 49/69
Hph •Vph •Brt •Pkg •Syn •Mem •Exe •Mut •Blk •Fnc •Hrt
•Vrt
↵
Example: Hph-112•Vph+009•Brt+000•Pkg1•Syn6•Mem1•Exe1•Mut0•Blk0•Fnc1•Hrt
031.47•Vrt059.94
↵
Where: Horizontal Shift (Hph) = -112
Vertical Shift (Vph) = +9
Level (Brt) = 0
Peaking (Pkg) = 1
Sync Mode (Syn) = 6 (Separate H & V with H = negative
and V = positive)
Memory Cycling (Mem) = 1 (Enabled)
Executive Mode (Exe) = 1 (On – Front Panel Locked Out)
Backlite Automode (Mut) = 0 (Off – Backlite stays lit)
Fade to Black (Blk) = 0 (Off – Not faded)
Menu Language (Fnc) = 1 (Menu language is English)
Horizontal Scan Rate (Hrt) = 31.47 kHz
Vertical Scan Rate (Vrt) = 59.94 Hz
Error Codes
Code Description
E10 Invalid command
E13 Invalid value (too large)
E14 Illegal command for this configuration (DIP Switch 1
is set ON for Digital Display Sync Processing and
Horizontal/Vertical Shift is requested)
