Extron RGB 302/304 Universal Interface • User’s Manual Page 3-11
Chapter 3 • Front Panel Menus
Confirm Reset Menu
The Confirm Reset menu actually resets the
RGB 302/304 to its factory settings. Press the
and keys simultaneously to reset or
press
MENU
to return to the default menu
cycle, or allow the time-out to occur. A reset
message will be displayed if reset was
selected.
By allowing the time-out to occur, you will
return to the default menu cycle.
Exit Menu
The Exit Menu menu allows the user to return
to the Image Controls menus by pressing the
MENU
key or the user may return to the default
menu cycle by either pressing
NEXT
or by
allowing the time-out to occur.
Default Settings on Power Up
On power up, the RGB 302/304 will default to the last
settings which were current just prior to the power off.
All 25 user-defined memory blocks will be saved if
Memory Cycling had been set On.
Default Settings on System Reset
On system reset, the RGB 302/304 will have the
following default settings:
• Menu language is set to English
• Backlite is set On
• Memory Cycling is set On
• Horizontal Shift is Center
• Vertical Shift is Center
• Level is Center
• Peaking is Minimum
• Sync Output is Automatic
All 25 user-defined memory blocks will be cleared, but
the 15 factory preset memory blocks will be retained.
