Extron RGB 302/304 Universal Interface • User’s Manual
Appendix A • Programmer’s Guide
Page A-3
Simple Commands
Commands
ASCII
Hex
Response
Video Level Control
specify video level
Y
+ 59
Brt
↵
increment video level
{ Y
7B + 59
Brt
↵
decrement video level
} Y
7D + 59
Brt
↵
Peaking Control
specify video peaking
_
+ 5F
Pkg
↵
increment video peaking
{
_
7B
+ 5F
Pkg
↵
decrement video peaking
{
_
7D
+ 5F
Pkg
↵
Horizontal Shift
specify horizontal shift
H
+ 48
Hph
↵
increment horizontal shift
{
H
7B
+ 48
Hph
↵
decrement horizontal shift
}
H
7D
+ 48
Hph
↵
Vertical Shift
specify vertical shift
/
+ 2F
Vph
↵
increment vertical shift
{
/
7B
+ F
Vph
↵
decrement vertical shift
}
/
7D
+ F
Vph
↵
Executive Mode (Front Panel Lockout)
Executive mode on
X
58
Exe 1
↵
Executive mode off
x
78
Exe 0
↵
Read DIP Switches
Read DIP switches
Esc p 00
↵
1B+70+30+30
00 Dds
•
Ser
•Trm
↵
Write Sync Mode
`
↵
+ 60
Syn
↵
Memory Cycling
Enable
.
2E
Mem 1
↵
Disable
,
2C
Mem 0
↵
Backlite Display Mode
Auto
S
53
Mut 1
↵
On
s
73
Mut 0
↵
Write ID Screen
Esc P 02 (up to 32 characters)
↵
1B+50+30+32
Updated
↵
Read ID Screen
Esc p 02
↵
1B+70+30+32 02
(up to 32 characters)
↵
Menu Language
English
# 1
23 + 31
Fnc 1
↵
Spanish
# 2
23 + 32
Fnc 2
↵
French
# 3
23 + 33
Fnc 3
↵
German
# 4
23 + 34
Fnc 4
↵
