Extron RGB 302/304 Universal Interface • User’s Manual Page 3-10
Chapter 3 • Front Panel Menus
Option Controls Menus
Among the menu options for the RGB 302/304
are the LCD Backlite, Memory Cycling, and
System Reset.
Press
NEXT
to go to the Backlite menu, or
press
MENU
to advance to the Exit Menu, or
allow the time-out to occur.
LCD Backlite Menu
The LCD Backlite menu allows the user to
permanently turn on the LCD backlite or
temporarily turn off the backlite . The
Auto state turns off the backlite whenever
there is no activity for 15 seconds. Auto will
turn on the backlite whenever any front panel
key is pressed.
Press the or or or key to
select between or . Then press
NEXT
to go to the Memory Cycling menu, or
press
MENU
to return to the Image Controls
menus, or allow the time-out to occur to save
any changes.
Memory Cycling Menu
The Memory Cycling menu allows the user
to turn the memory cycling feature On or Off.
Press the or or or key to
select between or . Then press
NEXT
to go to the System Reset menu, or
press
MENU
to return to the Image Controls
menus, or allow the time-out to occur to save
any changes.
Refer to the “Memory Cycling Feature”
section in Chapter 2.
System Reset Menu
The System Reset menu allows the user to
reset the RGB 302/304 to its factory settings.
Press the and keys simultaneously
to go to the Confirm Reset menu or press
NEXT
to return to the Option Controls menus,
or press
MENU
to return to the Image Controls
menus, or allow the time-out to occur.
